USB to Serial Converter

Easily connect serial devices through a USB port

Most modern computers and laptops don't have RS232 (DB9) ports, making the use of legacy peripherals and high-tech devices which connect with COM ports almost impossible. The Manhattan USB to Serial Converter — with its serial RS232 (DB9) ports and Prolific PL-2303 chipset — easily expands a single USB port to connect and support serial modems, barcode scanners, digital cameras, card readers, Ham/Amateur Radios, GPS, CNC machines, telescopes, embroidery machines, fuel injection controllers, PDUs, network switches and other devices.

Quality Construction and Easy Installation

Gold-plated contacts and rugged construction combine to offer a reliable connection between the computer and serial peripherals for consistent, trouble-free performance. Windows compatibility with plug-and-play installation and hot-swappability help provide seamless use without inconvenient and frustrating device conflicts.

• Quickly converts a USB port into two Serial/RS232/COM/DB9 ports
• The customizable and compatible Prolific PL-2303 chipset makes it the ideal solution for many OSs and platforms
• Easily connect most DB9/serial modems, digital cameras, label writers, barcode scanners, palm PCs, GPS, telescopes, CNC machines, embroidery machines, automotive control systems, digital organizers and much more
• Install as standard COM/RS-232 ports to provide serial connectivity for legacy and high-tech devices
• Chipsets PL-2303 and FTDI FT232RL configurations are also available at www.ManhattanProducts.com
• Windows compatible; plug and play; hot-swappable
• Three-Year Warranty

Standards and Certifcations

• CE

• FCC

• USB 1.0

• USB 1.1

• RoHS

• WEEE

  Connections

• USB port; type-A male

• 2 Serial/COM/RS232/DB9 ports; 9-pin male(s)

  General

• Transfer rate: up to 115 kbps

• Bus powered

• Overcurrent protection

• Prolific PL-2303 chipset

  Physical

• Cable length: 45 cm (18 in.)

• Weight: 225 g (7.9 oz.)

  System Requirements

• Windows XP/Vista/7/8/8.1/10 or Linux or Mac 9.x/10.x or above

  Package Contents

• USB to Serial Converter

• Instructions

• Additional SKUs

• Amazon ASIN: B002E4YMV8
• EAN: 0766623174947
• UPC: 766623174947
• ALSO: 1607036
• API: 77042



• Physical Specifications

• Product net weight: 0.07 kg
• Product gross weight: 0.12 kg
• Dimensions: 45 cm
• Packaging type: Blister
• Packaging dimensions: 160 x 136 x 51 [mm]
• Master Carton Quantity: 60
• Master Carton Weight: 8.50 kg
• Master Carton Dimensions: 450 x 410 x 455 [mm]

• Datasheet
• Datasheet     » Download


• Declaration of Conformity     » Download

• Driver
• MAC OS 10.x     » Download


• Windows 98Se/Me/2000/XP
  Install Shield V20026, 08/2004     » Download


• Linux 2.4 and Above     » Download


• MAC OS 8.x, 9.x     » Download


• Windows CE 3.0     » Download


• WinCE 5.0 Driver for x86
  WinCE 5.0 Driver for x86 Standard SDK     » Download


• Windows XP 64-bit
  Windows XP 64-bit Non-Logo Driver     » Download


• Windows 2000/XP/Vista/Server 2003/Server 2008/ Windows 7
  - Windows 98SE - Windows ME - Windows 2000 SP4 - Windows XP SP2 and above (32 & 64 bit) - Windows Server 2003 (32 & 64 bit) - Windows Server 2008 (32 & 64 bit) - Windows Vista (32 & 64 bit) - Windows 7 (32 & 64 bit) NOTE: For Windows 7, please use RC build 7100 or above.     » Download


• Drivers
  Latest Drivers for
  Mac 8.6 and above
  Linux
  Windows CE
  Windows XP, Vista, 7     » Download


• Driver 1.12.0 for Windows
  For Windows 10 (32 & 64-bit), Windows Vista, 7, 8, 8.1 (32 & 64-bit), Windows Server 2008, 2008R2, Server 2012, Server 2012R2 (64-bit), Windows 2000, XP, Server 2003 (32 & 64-bit)     » Download


• Mac OS X Universal Binary Driver v2.1.0
  For Mac OS Big Sur (version 11) - see NOTE below
  For Mac OS Catalina (version 10.15) .
  For Mac OS High Sierra (version 10.14)
  For Mac OS High Sierra (version 10.13)
  For Mac OS X Sierra (version 10.12)
  For Mac OS X El Capitan (version 10.11)
  For Mac OS X Yosemite (version 10.10)
  For Mac OS X Mavericks (version 10.9)
  For PL2303 H/HX/HXD/EA/RA/SA/TA/TB chip versions
  For Prolific USB VID_067B&PID_2303 Only
  For PL2303GC, GS, GT, GL, GE , GD, GR chip versions
  Includes Driver Installation Manual     » Download


• Windows 11
  Release Date: December 2021     » Download

• Manual
• Declaration of Conformity     » Download


• Declaration of Conformity     » Download


• Declaration of Conformity     » Download


• User Manual     » Download


• Quick Instruction Guide     » Download

• Utility
• Chipset Check
  (identify which chipset the converter uses)     » Download
